MQTT Gateway Overview

The MQTT Gateway is a Node.js protocol bridge that sits between ESP32 Cheeko devices and the LiveKit WebRTC cloud. Devices communicate using MQTT over TCP and raw UDP; the gateway translates those into LiveKit room connections and WebRTC audio tracks so the AI agents running in livekit-server can talk to children in real time.

MQTT (control messages)

ESP32 Device ──publish──► EMQX Broker ──republish──► internal/server-ingest ──► MQTTGateway
ESP32 Device ◄──subscribe── EMQX Broker ◄──publish── devices/p2p/<clientId> ◄── MQTTGateway
                                            (gateway sends directly, no republish)

UDP (audio)

ESP32 Device ◄──► MQTTGateway  (AES-128-CTR encrypted Opus, bidirectional)

Per-device internal structure

MQTTGateway
  └── VirtualMQTTConnection  (one per connected device)
        ├── LiveKitBridge ──► LiveKit Cloud Room ◄──► AI Agent (livekit-server)
        └── UDP crypto layer ◄──► ESP32 Device (encrypted audio)

---

Module Layer Table

Layer	Directory	Files	Responsibility
Entry point	/	app.js	Environment validation, Opus init, MQTTGateway startup, signal handlers
Gateway	gateway/	mqtt-gateway.js	Main orchestrator; EMQX connection, UDP socket, per-device lifecycle
Gateway	gateway/	device-handlers.js	Hello/goodbye/mode-change/character-change handler helpers
Gateway	gateway/	emqx-broker.js	Standalone EmqxBroker class with wildcard topic matching
Gateway	gateway/	udp-server.js	UdpServer class; AES-128-CTR encrypted send
Gateway	gateway/	udp-forwarder.js	UDP forwarding utilities
Gateway	gateway/	playback-control.js	Next/previous track control helpers
LiveKit	livekit/	livekit-bridge.js	Per-device LiveKitBridge; room creation, agent dispatch, audio forwarding
LiveKit	livekit/	audio-processor.js	Entropy-based Opus/PCM detection, silence checking, frame validation
LiveKit	livekit/	message-handlers.js	MessageHandlers; TTS start/stop, STT, emotion, LLM-thinking MQTT messages
LiveKit	livekit/	mcp-handler.js	McpHandler; MCP JSON-RPC request/response, volume debouncing
MQTT	mqtt/	message-parser.js	Parsing helpers for hello/goodbye/abort/mode-change/character-change
MQTT	mqtt/	virtual-connection.js	VirtualMQTTConnection; per-device MQTT session state, UDP crypto, bridge lifecycle
MQTT	/	mqtt-protocol.js	Raw MQTT 3.1.1 parser/encoder (CONNECT, PUBLISH, SUBSCRIBE, PINGREQ, DISCONNECT)
Core	core/	opus-initializer.js	@discordjs/opus encoder/decoder init
Core	core/	worker-pool-manager.js	WorkerPoolManager; 4–8 worker threads for audio encoding/decoding
Core	core/	media-api-client.js	Cerebrium API base URL and axios config for music/story bots
Core	core/	mem0-client.js, mem0-integration.js	Mem0 long-term memory fetch for agent dispatch metadata
Core	/	audio-worker.js	Worker thread; Opus encode/decode per session
Constants	constants/	audio.js	Sample rates, frame sizes, channel count
Utils	utils/	config-manager.js	JSON config file loader (mqtt.json)
Utils	utils/	logger.js	Pino/Winston logger
Utils	utils/	debug-logger.js, console-override.js	Debug namespace setup

---

Connection Lifecycle

1. Device connects

The ESP32 connects to the EMQX broker via MQTT/TCP. The gateway does not receive device connections directly — EMQX republishes all device messages to the internal/server-ingest topic, which the gateway subscribes to.

The device's MQTT client ID uses the format:

GID_test@@@68_25_dd_bb_f3_a0@@@<uuid>

Where the three parts separated by @@@ are the group ID, MAC address (underscores instead of colons), and a UUID.

2. Hello message received

EMQX republishes all device messages to internal/server-ingest. The gateway receives the message, extracts the MAC address from the client ID, and calls handleDeviceHello.

handleDeviceHello creates two objects stored in MQTTGateway:

Map	Key	Value
connections	connectionId (random 32-bit int)	VirtualMQTTConnection instance
deviceConnections	device MAC address	{ connectionId, connection }

3. Fast hello response (< 50 ms)

VirtualMQTTConnection.parseHelloMessage immediately:

• Generates a 16-byte AES key (crypto.randomBytes(16)) and a 16-byte nonce (from generateUdpHeader)
• Generates a session_id in the format <uuid>_<mac>_<roomType> (default room type: conversation)
• Sends a hello response back via MQTT on devices/p2p/<fullClientId> with UDP connection parameters

4. Deferred setup (background)

While the device starts streaming audio, the gateway runs parallel DB queries to fetch:

• Room type (conversation / music / story)
• PTT mode (auto / manual)
• Current character (e.g., Cheeko, Math Tutor)
• Child profile
• Mem0 long-term memories

After queries complete it:

1. Sends a mode_update MQTT message with the actual values
2. Creates a LiveKitBridge and connects to a LiveKit room named <uuid>_<mac>_<roomType>
3. Dispatches the appropriate AI agent via AgentDispatchClient

5. Audio streaming

UDP packets arrive at MQTTGateway.onUdpMessage. The 16-byte header is parsed to extract the connectionId, which looks up the VirtualMQTTConnection. The connection decrypts the payload and forwards decoded PCM audio to LiveKit. Audio coming back from LiveKit is encoded to Opus and sent as encrypted UDP to the device.

6. Cleanup

When a goodbye message is received (or an inactivity timeout fires), VirtualMQTTConnection.parseOtherMessage notifies the agent via a LiveKit data channel disconnect_agent message, then closes the LiveKitBridge. The entries are removed from both gateway maps. Ghost room cleanup also runs every 5 minutes to remove any LiveKit rooms that are empty, have only agents (no device), or are older than 60 minutes.

---

Key Data Structures

VirtualMQTTConnection

One instance per connected device, stored in MQTTGateway.connections.

Field	Type	Description
deviceId	string	Device MAC address (aa:bb:cc:dd:ee:ff)
connectionId	number	Random 32-bit integer, used as UDP cookie
macAddress	string	Colon-separated MAC
groupId	string	First segment of MQTT client ID
uuid	string	Third segment of MQTT client ID
bridge	LiveKitBridge	LiveKit room bridge (null until deferred setup completes)
roomType	string	conversation, music, or story
udp.key	Buffer	16-byte AES-128 encryption key
udp.nonce	Buffer	16-byte AES-128-CTR IV
udp.encryption	string	Always "aes-128-ctr"
udp.session_id	string	LiveKit room name
udp.remoteAddress	Object	{ address, port } of device UDP endpoint
lastActivityTime	number	Unix ms; used for 2-minute inactivity timeout
sessionStartTime	number	Unix ms; max session duration 60 minutes

LiveKitBridge

One instance per active device session, held by VirtualMQTTConnection.bridge.

Connects the gateway as a participant in the LiveKit room, publishes device audio as a track, subscribes to agent audio tracks, and routes data channel messages in both directions.

---

Running

cd main/mqtt-gateway
npm install
node app.js

---

Configuration File (config/mqtt.json)

The gateway reads MQTT broker and LiveKit credentials from config/mqtt.json. The ConfigManager watches this file for live-reload — changes take effect without restarting the process.

{
  "debug": false,
  "mqtt_broker": {
    "host": "YOUR_EMQX_HOST",
    "port": 1883,
    "protocol": "mqtt",
    "keepalive": 60,
    "clean": true,
    "reconnectPeriod": 1000,
    "connectTimeout": 30000
  },
  "livekit": {
    "url": "wss://your-project.livekit.cloud",
    "api_key": "YOUR_LIVEKIT_API_KEY",
    "api_secret": "YOUR_LIVEKIT_API_SECRET"
  }
}

Field	Description
debug	Enable verbose debug logging
mqtt_broker.host	EMQX broker hostname or IP
mqtt_broker.port	EMQX broker port (default 1883)
mqtt_broker.protocol	mqtt (plain) or mqtts (TLS)
mqtt_broker.keepalive	MQTT keepalive interval in seconds
mqtt_broker.clean	Start with a clean MQTT session
mqtt_broker.reconnectPeriod	Auto-reconnect interval in ms
mqtt_broker.connectTimeout	Connection timeout in ms
livekit.url	LiveKit Cloud WebSocket URL
livekit.api_key	LiveKit API key
livekit.api_secret	LiveKit API secret

Environment variables (EMQX_HOST, LIVEKIT_URL, etc.) override the corresponding mqtt.json values when set.

---

Environment Variables

Variable	Default	Description
UDP_PORT	1883	UDP port for device audio streaming
PUBLIC_IP	127.0.0.1	Public IP address returned to devices in hello response
EMQX_HOST	(from mqtt.json)	EMQX broker hostname
EMQX_PORT	(from mqtt.json)	EMQX broker port
EMQX_PROTOCOL	(from mqtt.json)	MQTT protocol (mqtt, mqtts)
LIVEKIT_URL	(from mqtt.json)	LiveKit server WebSocket URL
LIVEKIT_API_KEY	(from mqtt.json)	LiveKit API key
LIVEKIT_API_SECRET	(from mqtt.json)	LiveKit API secret
MANAGER_API_URL	—	Base URL for manager API, e.g. http://localhost:3000/toy
MANAGER_API_SECRET	—	Secret header value for internal manager API calls
MEDIA_API_BASE	Cerebrium endpoint	Base URL for music/story bot API
CEREBRIUM_API_TOKEN	—	Required. Bearer token for Cerebrium API. Process exits if unset.
LOKI_HOST	—	Optional Grafana Loki host for centralized logging
