Architecture Overview

Architecture

System Diagram

┌─────────────────────────────────────────────────────────────────────┐
│                        ESP32 Device (Firmware)                      │
│  - State machine (idle/connecting/listening/speaking/...)           │
│  - MQTT client                                                       │
│  - UDP socket (AES-128-CTR encrypted Opus audio)                    │
│  - SD card (RFID skill cache)                                       │
│  - RFID reader                                                       │
└──────────────┬──────────────────────────────┬───────────────────────┘
               │ MQTT (publish/subscribe)      │ UDP (audio packets)
               ▼                              ▼
┌─────────────────────────────────────────────────────────────────────┐
│                   MQTT/UDP Gateway (Node.js)                        │
│  main/mqtt-gateway/                                                  │
│  - EMQX MQTT broker bridge                                           │
│  - UDP server (AES-128-CTR encrypted Opus audio)                    │
│  - VirtualMQTTConnection per device                                  │
│  - LiveKitBridge (per device session)                               │
│  - Calls Manager API for device config/RFID lookups                 │
└──────────────┬──────────────────────────────┬───────────────────────┘
               │ REST HTTP                     │ LiveKit SDK (WebRTC)
               ▼                              ▼
┌─────────────────────────┐      ┌────────────────────────────────────┐
│   Manager API (Node.js) │      │   LiveKit Cloud + livekit-server   │
│   main/manager-api-node │      │   workers/cheeko_worker.py         │
│   - Device registry      │      │   workers/math_tutor_worker.py    │
│   - OTA check/activate   │      │   workers/riddle_solver_worker.py │
│   - RFID card lookup     │      │   workers/word_ladder_worker.py   │
│   - Agent config/prompts │      └────────────────────────────────────┘
│   - Content manifest     │
│   - Child profiles       │
│   - Analytics            │
└─────────────────────────┘

All device-to-server communication starts with the Manager API (OTA), then shifts to the MQTT Gateway for real-time protocol.

Service Port Map

Service	Language	Port	Base Path	Notes
manager-api-node	Node.js / Express	8002	`/toy`	Active implementation
mqtt-gateway	Node.js	—	—	MQTT + UDP bridge
livekit-server	Python	—	—	LiveKit agent workers
manager-web	Vue.js	—	—	Admin dashboard
MQTT broker (EMQX)	—	1883	—	Device MQTT endpoint
Swagger / API Docs	—	8002	`/toy/doc.html`	OpenAPI UI

Boot-to-Conversation Flow: 8 Phases

Phase	Name	Description
1	OTA Check	Device POSTs to `/toy/ota/` — gets MQTT credentials, firmware info, activation status, server time
2	Activation Loop	If not activated, device polls `POST /toy/ota/activate` until it receives `200 success`
3	MQTT Connect + Hello	Device connects to EMQX broker and publishes `{"type":"hello"}` — gateway responds with server hello containing UDP credentials
4	UDP Channel Setup	Device opens UDP socket to the address in server hello; configures AES-128-CTR cipher
5	Mode Update (Deferred)	Gateway queries Manager API for device mode, character, and child profile; sends `{"type":"mode_update"}` to device
6	Conversation Loop	Bidirectional voice: device streams mic audio uplink (UDP), gateway streams TTS audio downlink (UDP); MQTT carries control messages
7	Abort / Interrupt	Device sends `{"type":"abort"}` to interrupt the assistant mid-speech; gateway stops TTS and waits for next listen
8	Session End	Either side sends `{"type":"goodbye"}`; device closes UDP channel and returns to idle without disconnecting MQTT

Device Boot
    │
    ▼
[Phase 1] POST /toy/ota/
    │   ← Returns: mqtt creds, firmware info, activation status, server_time
    │
    ├─ If firmware update available → download firmware → reboot
    │
    ├─ If not activated → [Phase 2] POST /toy/ota/activate (loop)
    │
    ▼
[Phase 3] MQTT CONNECT (using OTA credentials)
    │
    ▼
Firmware publishes: {"type":"hello", ...}  →  Gateway
    │
    ▼
[Phase 4] Gateway returns: {"type":"hello", "udp":{server,port,key,nonce,...}, ...}
    │
    ▼
Firmware opens UDP socket to server:port
    │
    ▼
[Phase 5] Gateway sends (deferred): {"type":"mode_update", ...}
    │   (after querying Manager API for device mode/character/profile)
    │
    ▼
[Phase 6] Conversation loop begins
    │
    ├─ Firmware: {"type":"listen","state":"start","mode":"auto|manual|realtime"}
    ├─ Firmware→Gateway: UDP encrypted Opus audio packets (uplink)
    ├─ Firmware: {"type":"speech_end"}
    ├─ Gateway→Firmware: {"type":"llm","state":"think"}
    ├─ Gateway→Firmware: {"type":"tts","state":"start"}
    ├─ Gateway→Firmware: UDP encrypted Opus audio packets (downlink, 24kHz)
    ├─ Gateway→Firmware: {"type":"stt","text":"..."}  (user transcript)
    ├─ Gateway→Firmware: {"type":"llm","text":"...","emotion":"..."}
    └─ Gateway→Firmware: {"type":"tts","state":"stop"}

Component Responsibilities

ESP32 Firmware

Implements the device state machine (starting → activating → idle → connecting → listening → speaking)
Manages MQTT connection lifecycle and publishes/subscribes to control topics
Sends mic audio as AES-128-CTR encrypted Opus frames over UDP (16kHz uplink)
Plays TTS audio received over UDP (24kHz downlink)
Handles RFID card tap events; maintains local SD card cache of content skills

mqtt-gateway

The gateway is the real-time protocol hub. It is organized into layers under main/mqtt-gateway/:

Layer	Directory	Purpose
Protocol handlers	`gateway/`	MQTT/UDP handlers: `mqtt-gateway.js`, `udp-server.js`, `emqx-broker.js`
LiveKit integration	`livekit/`	`livekit-bridge.js`, `audio-processor.js`, `mcp-handler.js`
Shared utilities	`core/`	`opus-initializer.js`, `worker-pool-manager.js`
Config / logging	`utils/`	Logging, config management

For each device session the gateway maintains a VirtualMQTTConnection and a LiveKitBridge. It resamples uplink audio from 16kHz to 24kHz before forwarding to LiveKit.

manager-api-node

REST API serving both the gateway (config lookups) and the firmware (OTA). Base path /toy. Modules:

Module	Path	Role
agent	`src/routes/agent.routes.js`	Agent config and prompts per MAC
device	`src/routes/device.routes.js`	Device registry, mode, character
content	`src/routes/content.routes.js`	Music, stories, textbooks
rfid	`src/routes/rfid.routes.js`	RFID card lookup and content manifest
security / auth	`src/routes/auth.routes.js`	User authentication (Supabase Auth)
analytics	`src/routes/analytics.routes.js`	Game sessions, media playback, usage stats
profile	`src/routes/profile.routes.js`	Child profiles (mobile API)

livekit-server

Python-based LiveKit agent workers. Each worker handles a specific mode:

Worker	Character	Triggered by
`cheeko_worker.py`	Cheeko	Default / `conversation` mode
`math_tutor_worker.py`	Math Tutor	Character set to `Math Tutor`
`riddle_solver_worker.py`	Riddle Solver	Character set to `Riddle Solver`
`word_ladder_worker.py`	Word Ladder	Character set to `Word Ladder`

The gateway resolves the active character (from Manager API) and dispatches the corresponding agent worker into the LiveKit room.

External Services

Service	Purpose
LiveKit Cloud	Real-time voice/video WebRTC infrastructure
Groq / Google	LLM providers for conversation
ElevenLabs / Edge-TTS	Text-to-speech synthesis
Deepgram / Whisper	Speech-to-text transcription
Qdrant	Vector search for semantic content matching
Mem0	Memory and personalization across sessions
Grafana Loki	Centralized log aggregation
Supabase	PostgreSQL database and auth for manager-api-node
EMQX	MQTT broker for device-to-gateway messaging

CI/CD

CircleCI (.circleci/config.yml) handles branch-specific deployments, Docker builds for each component, and EMQX broker deployment.
