Firmware Integration Guide

Firmware

Audience: Firmware engineers implementing the Cheeko protocol on ESP32 devices.

Covers: Every HTTP API call, every MQTT message (both directions), every UDP packet contract, all state machine transitions, all RFID flows.

System Overview
Full Boot-to-Conversation Flow
Phase 1 — OTA Check
Phase 2 — Activation Loop
Phase 3 — MQTT Connect and Hello Handshake
Phase 4 — UDP Channel Setup
Phase 5 — Mode Update (Deferred)
Phase 6 — Conversation Loop
Phase 7 — Abort / Interrupt
Phase 8 — Session End
RFID Card Flow
Device State Machine
MQTT Message Reference
UDP Packet Format
Manager API Endpoints
Gateway Internal API Calls
LiveKit Data Channel Messages
Timeouts and Retries
Persistence Keys
Minimal Conformance Checklist

1. System Overview

┌─────────────────────────────────────────────────────────────────────┐
│                        ESP32 Device (Firmware)                      │
│  - State machine (idle/connecting/listening/speaking/...)           │
│  - MQTT client                                                       │
│  - UDP socket (AES-128-CTR encrypted Opus audio)                    │
│  - SD card (RFID skill cache)                                       │
│  - RFID reader                                                       │
└──────────────┬──────────────────────────────┬───────────────────────┘
               │ MQTT (publish/subscribe)      │ UDP (audio packets)
               ▼                              ▼
┌─────────────────────────────────────────────────────────────────────┐
│                   MQTT/UDP Gateway (Node.js)                        │
│  main/mqtt-gateway/                                                  │
│  - EMQX MQTT broker bridge                                           │
│  - UDP server (AES-128-CTR encrypted Opus audio)                    │
│  - VirtualMQTTConnection per device                                  │
│  - LiveKitBridge (per device session)                               │
│  - Calls Manager API for device config/RFID lookups                 │
└──────────────┬──────────────────────────────┬───────────────────────┘
               │ REST HTTP                     │ LiveKit SDK (WebRTC)
               ▼                              ▼
┌─────────────────────────┐      ┌────────────────────────────────────┐
│   Manager API (Node.js) │      │   LiveKit Cloud + livekit-server   │
│   main/manager-api-node │      │   workers/cheeko_worker.py         │
│   - Device registry      │      │   workers/math_tutor_worker.py    │
│   - OTA check/activate   │      │   workers/riddle_solver_worker.py │
│   - RFID card lookup     │      │   workers/word_ladder_worker.py   │
│   - Agent config/prompts │      └────────────────────────────────────┘
│   - Content manifest     │
│   - Child profiles       │
│   - Analytics            │
└─────────────────────────┘

All device-to-server communication starts with the Manager API (OTA check), then shifts to the MQTT Gateway for all real-time protocol traffic.

What the Firmware Must Implement

At minimum, implement these flows:

Boot and network bring-up.
OTA check (/toy/ota/) and optional activation loop (/toy/ota/activate).
MQTT connect using OTA-provided credentials.
MQTT hello exchange and UDP channel setup.
Audio conversation loop:
- send listen states
- stream encrypted audio over UDP
- handle tts/stt/llm messages
- send speech_end and abort when required
RFID flow:
- local SD lookup first
- if unknown, send card_lookup
- on card_content, download assets to SD then play
- on card_ai, switch to conversation behavior
Session lifecycle and recovery:
- handle goodbye
- handle timeouts
- recover after disconnects

External Interfaces Firmware Uses

Manager API — base context path /toy:

POST /toy/ota/
POST /toy/ota/activate
OTA binary URL from OTA response: /toy/otaMag/download/<id>

MQTT Gateway — firmware publishes and subscribes:

Publish to publish_topic from OTA response (currently device-server)
Subscribe to subscribe_topic from OTA response
If subscribe_topic is "null" (string) or empty, fall back to devices/p2p/<client_id>

UDP Audio Channel — negotiated via MQTT hello / server hello response.

2. Full Boot-to-Conversation Flow

Device Boot
    │
    ▼
[Phase 1] POST /toy/ota/
    │   ← Returns: mqtt creds, firmware info, activation status, server_time
    │
    ├─ If firmware update available → download firmware → reboot
    │
    ├─ If not activated → [Phase 2] POST /toy/ota/activate (loop)
    │
    ▼
[Phase 3] MQTT CONNECT (using OTA credentials)
    │
    ▼
Firmware publishes: {"type":"hello", ...}  →  Gateway
    │
    ▼
[Phase 4] Gateway returns: {"type":"hello", "udp":{server,port,key,nonce,...}, ...}
    │
    ▼
Firmware opens UDP socket to server:port
    │
    ▼
[Phase 5] Gateway sends (deferred): {"type":"mode_update", ...}
    │   (after querying Manager API for device mode/character/profile)
    │
    ▼
[Phase 6] Conversation loop begins
    │
    ├─ Firmware: {"type":"listen","state":"start","mode":"auto|manual|realtime"}
    ├─ Firmware→Gateway: UDP encrypted Opus audio packets (uplink)
    ├─ Firmware: {"type":"speech_end"}
    ├─ Gateway→Firmware: {"type":"llm","state":"think"}
    ├─ Gateway→Firmware: {"type":"tts","state":"start"}
    ├─ Gateway→Firmware: UDP encrypted Opus audio packets (downlink, 24kHz)
    ├─ Gateway→Firmware: {"type":"stt","text":"..."}  (user transcript)
    ├─ Gateway→Firmware: {"type":"llm","text":"...","emotion":"..."}
    └─ Gateway→Firmware: {"type":"tts","state":"stop"}

3. Phase 1 — OTA Check

Request

Endpoint: POST /toy/ota/

Headers (required):

Device-Id: AA:BB:CC:DD:EE:FF      ← MAC address (used as device identifier)
Client-Id: GID_test@@@AA_BB_CC_DD_EE_FF@@@<uuid>
Activation-Version: <string>
Serial-Number: <string>            ← if available
Content-Type: application/json
User-Agent: <firmware user agent>
Accept-Language: en-US

Body:

{
  "mac_address": "AA:BB:CC:DD:EE:FF",
  "version": "1.0.5",
  "flash_size": 4194304,
  "chip_model_name": "ESP32-S3",
  "chip_info": {
    "model": 9,
    "cores": 2,
    "revision": 0,
    "features": 18
  },
  "application": {
    "name": "cheeko",
    "compile_time": "Jan 01 2025 00:00:00",
    "idf_version": "v5.1.2"
  },
  "board": "jiuchuan-s3",
  "ota": {
    "label": "factory",
    "state": "VALID"
  }
}

Response

Returns raw JSON (not wrapped in {code, msg, data}):

{
  "server_time": {
    "timestamp": 1710000000000,
    "timeZone": "Asia/Kolkata",
    "timezone_offset": 330
  },
  "firmware": {
    "version": "1.2.3",
    "url": "http://<host>/toy/otaMag/download/<id>",
    "force": 0,
    "size": 1234567,
    "name": "cheeko_v1.2.3.bin",
    "remark": "Stability improvements"
  },
  "websocket": {
    "url": "ws://<host>/ws"
  },
  "mqtt": {
    "broker": "<emqx-host>",
    "port": 1883,
    "endpoint": "<host>:<port>",
    "client_id": "GID_test@@@AA_BB_CC_DD_EE_FF@@@<uuid>",
    "username": "<mqtt-username>",
    "password": "<mqtt-password>",
    "publish_topic": "device-server",
    "subscribe_topic": "null"
  },
  "activation": {
    "code": "123456",
    "message": "https://app.cheeko.ai/activate\n123456",
    "challenge": "AA:BB:CC:DD:EE:FF"
  }
}

Response Field Reference

Field	Type	Notes
`server_time.timestamp`	number	Unix epoch milliseconds; use to sync device clock
`server_time.timeZone`	string	IANA timezone name
`server_time.timezone_offset`	number	UTC offset in minutes
`firmware`	object	May be absent — if absent, no update needed
`firmware.version`	string	New firmware version string
`firmware.url`	string	Full URL to download OTA binary
`firmware.force`	number	`1` = must update before connecting; `0` = optional
`firmware.size`	number	Binary size in bytes
`websocket.url`	string	WebSocket fallback URL (persist to NVS)
`mqtt.endpoint`	string	`<host>:<port>` TCP address for MQTT broker
`mqtt.client_id`	string	Format: `GID_test@@@<MAC_no_colon>@@@<uuid>`
`mqtt.publish_topic`	string	Topic firmware publishes all messages to
`mqtt.subscribe_topic`	string	`"null"` (literal string) → use fallback topic
`activation`	object	May be absent — if absent, device is already activated
`activation.code`	string	Display this code to user during activation
`activation.challenge`	string	MAC address used in HMAC activation

Firmware Rules

firmware field may be absent → no update needed.
activation field may be absent → device already activated.
subscribe_topic = "null" (string) → firmware falls back to devices/p2p/<client_id>.
Persist mqtt, websocket, and server_time to NVS for reconnect after reboot.
If firmware.force = 1, must update immediately before connecting to MQTT.
OTA check retry: up to 10 times with exponential backoff starting at 10s.

4. Phase 2 — Activation Loop

Endpoint: POST /toy/ota/activate

Headers:

Device-Id: AA:BB:CC:DD:EE:FF
Content-Type: application/json

Body (with serial-number HMAC flow):

{
  "algorithm": "hmac-sha256",
  "serial_number": "<serial>",
  "challenge": "AA:BB:CC:DD:EE:FF",
  "hmac": "<hex-hmac>"
}

Responses

HTTP Status	Body	Meaning
`200`	`success` (plain text)	Device is activated — proceed to MQTT connect
`202`	(empty)	Not activated yet — retry after ~3s
`202`	(empty)	Any error condition also returns 202

Firmware Rules

Loop polling until 200 success.
Retry up to 10 times per cycle, ~3s between each attempt.
Display activation code (activation.code from OTA response) to user during the loop.
Only after activation success: proceed to MQTT connect.

activating state:
    │
    ├─ POST /toy/ota/activate
    │   ├─ 200 "success" → proceed to MQTT connect
    │   └─ 202 → wait 3s → retry (up to 10 times)
    │
    └─ After 10 failures → wait ~10s → retry full cycle

5. Phase 3 — MQTT Connect and Hello Handshake

5.1 MQTT Connection Parameters

Use values from the OTA response mqtt object:

Field	Usage
`endpoint`	`<host>:<port>` — TCP address for MQTT broker
`client_id`	MQTT client ID: format `GID_test@@@<MAC_no_colon>@@@<uuid>`
`username`	MQTT username
`password`	MQTT password
`publish_topic`	Topic firmware publishes to — usually `device-server`
`subscribe_topic`	Topic firmware subscribes to — usually `"null"` (string) → use fallback

Subscribe topic fallback (when subscribe_topic is "null" or empty):

devices/p2p/<client_id>

5.2 Device Hello Message

After MQTT connect, firmware immediately publishes a hello message.

Firmware publishes to: device-server (or publish_topic from OTA)

{
  "type": "hello",
  "version": 3,
  "transport": "udp",
  "features": {
    "mcp": true
  },
  "audio_params": {
    "format": "opus",
    "sample_rate": 16000,
    "channels": 1,
    "frame_duration": 60
  }
}

Field notes:

Field	Value	Notes
`version`	`3`	Current protocol version
`transport`	`"udp"`	Requests UDP audio channel
`features.mcp`	`true`	Device supports MCP tool calls (volume, LED, etc.)
`audio_params.format`	`"opus"`	Codec
`audio_params.sample_rate`	`16000`	Device records at 16kHz; gateway resamples to 24kHz for LiveKit
`audio_params.channels`	`1`	Mono
`audio_params.frame_duration`	`60`	60ms Opus frames

5.3 Gateway Processing on Hello

When the gateway receives hello from the device:

Parses client_id → extracts MAC, UUID, GID.
Generates session_id = <uuid>_<macNoColon>_<mode>.
Generates UDP encryption key/nonce.
Generates connection_id (random 32-bit).
Immediately sends server hello (see 5.4 below).
In background: queries Manager API for device mode, character, child profile.
After background queries complete: sends mode_update and dispatches LiveKit agent.

5.4 Gateway Server Hello (Response)

Gateway publishes to: devices/p2p/<client_id>

{
  "type": "hello",
  "version": 3,
  "mode": "conversation",
  "session_id": "<uuid>_<macNoColon>_conversation",
  "transport": "udp",
  "udp": {
    "server": "<public-ip>",
    "port": 1883,
    "encryption": "aes-128-ctr",
    "key": "<32-hex-chars>",
    "nonce": "<32-hex-chars>",
    "connection_id": 123456789,
    "cookie": 123456789
  },
  "audio_params": {
    "sample_rate": 24000,
    "channels": 1,
    "frame_duration": 60,
    "format": "opus"
  }
}

Server hello field notes:

Field	Notes
`session_id`	Must be included in all subsequent MQTT messages from firmware
`audio_params.sample_rate`	`24000` — server sends 24kHz downlink audio (different from device uplink 16kHz)
`udp.key`	AES-128-CTR encryption key (hex string, 16 bytes = 32 hex chars)
`udp.nonce`	AES-128-CTR nonce (hex string, 16 bytes = 32 hex chars)
`udp.connection_id`	Used in every UDP packet header
`udp.cookie`	Same as `connection_id` — duplicate field for compatibility

Timeout: Firmware must wait max 10s for server hello. If not received, retry or fall back.

6. Phase 4 — UDP Channel Setup

After receiving server hello, firmware must:

Open a UDP socket to udp.server : udp.port.
Configure AES-128-CTR cipher with udp.key (hex-decoded to 16 bytes) and udp.nonce (hex-decoded to 16 bytes).
Start listening for downlink audio from the gateway.

Uplink (firmware → gateway): Mic audio encoded as 16kHz Opus, AES-128-CTR encrypted. Downlink (gateway → firmware): Assistant TTS audio at 24kHz Opus, AES-128-CTR encrypted.

See Section 14 for the exact byte layout of each packet.

7. Phase 5 — Mode Update (Deferred)

After hello, the gateway queries the Manager API in background before sending mode_update. This happens asynchronously — firmware may receive mode_update a moment after the server hello.

Gateway API Calls on Hello

API Call	Purpose
`GET /toy/device/:mac/mode`	Get device mode (`conversation`/`music`/`story`)
`GET /toy/device/:mac/device-mode`	Get listening mode (`auto`/`manual`)
`GET /toy/agent/device/:mac/current-character`	Get current character name
`POST /toy/config/child-profile-by-mac`	Get child profile (age, name, preferences)

mode_update Message

Gateway → Firmware (MQTT):

{
  "type": "mode_update",
  "mode": "conversation",
  "listening_mode": "auto",
  "character": "Cheeko",
  "session_id": "<session_id>",
  "timestamp": 1710000000000
}

mode values: conversation | music | story

listening_mode values: auto | manual | realtime

character values and their corresponding LiveKit agents:

`character`	LiveKit Agent Dispatched
`Cheeko`	`cheeko-agent`
`Math Tutor`	`math-tutor-agent`
`Riddle Solver`	`riddle-solver-agent`
`Word Ladder`	`word-ladder-agent`

After sending mode_update, the gateway dispatches the appropriate LiveKit agent worker for the session.

8. Phase 6 — Conversation Loop

8.1 User Starts Speaking (PTT or Wake Word)

Firmware → Gateway (MQTT):

{"session_id":"...","type":"listen","state":"start","mode":"manual"}

mode: manual (PTT button held), auto (VAD-based), realtime (continuous)
Firmware simultaneously starts sending UDP audio packets (mic uplink).

8.2 Wake Word Detection Event

Firmware → Gateway (MQTT):

{"session_id":"...","type":"listen","state":"detect","text":"hey cheeko"}

Used to log/surface wake word detection event. This is separate from listen start.

8.3 User Stops Speaking (PTT Release)

Firmware → Gateway (MQTT):

{"session_id":"...","type":"speech_end"}

Firmware stops mic/UDP uplink.
Firmware enters "thinking" UI state (waiting for TTS).
Thinking timeout: 20s with no tts start → close session, go idle.

8.4 Gateway Thinking Indicator

Gateway → Firmware (MQTT):

{"type":"llm","state":"think","session_id":"..."}

Firmware should show thinking/loading animation.

8.5 Gateway Starts Speaking

Gateway → Firmware (MQTT):

{"type":"tts","state":"start","session_id":"...","text":"Hello! How can I help you today?"}

text is optional (may be empty string or absent).
On this message, firmware transitions to speaking state.
Firmware starts playing downlink UDP audio.

8.6 Gateway Sentence Start (Text Update)

Gateway → Firmware (MQTT):

{"type":"tts","state":"sentence_start","session_id":"...","text":"Hello! How can I help you today?"}

Optional — used for on-screen transcript of assistant speech. No state transition required.

8.7 User Transcript from STT

Gateway → Firmware (MQTT):

{"type":"stt","text":"Tell me a story about a fox","session_id":"..."}

Carries recognized user speech text.
No stt start/stop states exist — just text update messages.
Firmware uses this for on-screen display only; no transport state change.

8.8 LLM Text and Emotion

Gateway → Firmware (MQTT):

{"type":"llm","text":"Once upon a time...","session_id":"..."}
{"type":"llm","text":"I'm so happy you asked!","emotion":"happy","session_id":"..."}

Known emotion values: happy | sad | thinking | excited | circle_xmark

Used for facial animation / LED / display updates. No transport state change required.

8.9 Gateway Stops Speaking

Gateway → Firmware (MQTT):

{"type":"tts","state":"stop","session_id":"..."}

Firmware state transition on tts stop:

Listening mode	Next state
`manual`	→ `idle`
`auto`	→ `listening` (send `listen start` automatically)
`realtime`	→ `listening` (send `listen start` automatically)

8.10 Alert Message

Gateway → Firmware (MQTT):

{
  "type": "alert",
  "status": "error",
  "message": "Connection to AI service failed",
  "emotion": "circle_xmark",
  "session_id": "..."
}

Used for error conditions. Firmware should show error UI.

8.11 Agent Ready Signal

Gateway → Firmware (MQTT):

{"type":"agent_ready"}

Sent when the LiveKit agent has joined the room and is ready to process audio. Firmware can use this to know the AI is ready.

8.12 Conversation Timing Diagram

Firmware              Gateway/LiveKit
   │                       │
   │── listen(start) ──────►│
   │══ UDP audio uplink ═══►│
   │── speech_end ──────────►│
   │                        │  (STT + LLM processing)
   │◄── llm(think) ─────────│
   │◄── tts(start) ─────────│
   │◄══ UDP audio downlink ═│
   │◄── stt(text) ──────────│  (user transcript)
   │◄── llm(text/emotion) ──│  (assistant text)
   │◄── tts(stop) ──────────│
   │                        │
   │  (manual) → idle       │
   │  (auto/realtime) ──────►│── listen(start) again

9. Phase 7 — Abort / Interrupt

9.1 Firmware Interrupts During Speaking

Firmware → Gateway (MQTT):

{"session_id":"...","type":"abort","reason":"wake_word_detected"}

reason values: wake_word_detected | button_pressed | user_interrupt

9.2 Firmware Behavior on Sending Abort

Clear pending UDP uplink buffers.
Immediately start a new listen start.
Do NOT full reconnect — reuse the existing session and UDP channel.

9.3 Gateway Behavior on Receiving Abort

Sends abort event to LiveKit data channel → agent stops TTS generation.
Stops sending downlink audio.
Waits for next listen start.

10. Phase 8 — Session End

10.1 Device Initiates Goodbye

Firmware → Gateway (MQTT):

{"session_id":"...","type":"goodbye"}

10.2 Gateway Initiates Goodbye (Inactivity Timeout)

Gateway → Firmware (MQTT):

{"type":"goodbye","session_id":"...","reason":"inactivity_timeout"}

reason values: inactivity_timeout | error | disconnect | mode_change

10.3 Firmware Behavior on Receiving Goodbye

Close UDP channel.
Reset session variables (session_id, crypto state).
Transition to idle.
Do NOT MQTT disconnect — stay connected for the next session.

11. RFID Card Flow

11.1 Card Tapped — Local SD Cache Check

Card tapped
    │
    ▼
Check SD: /sdcard/cheeko/cardmap.jsn  →  UID present?
    │
    ├─ Yes: check /sdcard/cheeko/skills/<skill_id>/manifest.jsn  →  exists?
    │           │
    │           ├─ Yes → Play immediately (offline, no network needed)
    │           │         audio: /sdcard/cheeko/skills/<skill_id>/audio/*.mp3
    │           │         images: /sdcard/cheeko/skills/<skill_id>/images/*
    │           │
    │           └─ No (incomplete download) → treat as unknown, send card_lookup
    │
    └─ No → send card_lookup to gateway

Local-first path must be fast and offline-capable.
Keep a persistent UID -> skill_id map in cardmap.jsn.
Consider a skill valid only if manifest.jsn exists (completion marker).

11.2 Card Lookup Request (Unknown Card)

Firmware → Gateway (MQTT):

{"session_id":"...","type":"card_lookup","rfid_uid":"04A1B2C3D4"}

Gateway processing:

Calls Manager API: GET /toy/admin/rfid/card/lookup/<rfidUid>
Returns one of three responses (see 11.3–11.5 below).

Timeout: 10s waiting for card response. If no response, show "card not recognized".

11.3 Response A — Unknown Card

Gateway → Firmware (MQTT):

{"type":"card_unknown","rfid_uid":"04A1B2C3D4"}

Firmware: Show "card not recognized" UX.

11.4 Response B — AI Card

Gateway → Firmware (MQTT):

{"type":"card_ai","rfid_uid":"04A1B2C3D4"}

Firmware behavior:

Store UID → AI mapping locally.
If device is idle: prewarm conversation channel (send hello if not already connected).
On user action (button/wake word): start conversation immediately from prewarmed state.
On card removal: cancel prewarm, do not enter deep sleep while prewarmed.

Prewarm flow:

card_ai received
    │
    ├─ Already connected (hello done) → keep channel, mark as prewarmed
    │
    └─ Not connected → send hello → wait for server hello → open UDP → stay in prewarm state

User presses talk button:
    │
    └─ Send listen(start) immediately (channel already open)

11.5 Response C — Content Card (Story/Song/Habit/Rhyme Pack)

Gateway → Firmware (MQTT):

{
  "type": "card_content",
  "rfid_uid": "04A1B2C3D4",
  "skill_id": "skill_abc123",
  "skill_name": "The Hungry Fox Story",
  "version": 1,
  "audio": [
    {"index": 1, "url": "https://cdn.cheeko.ai/skills/abc123/audio/track1.mp3"},
    {"index": 2, "url": "https://cdn.cheeko.ai/skills/abc123/audio/track2.mp3"}
  ],
  "images": [
    {"index": 1, "url": "https://cdn.cheeko.ai/skills/abc123/images/page1.jpg"},
    {"index": 2, "url": "https://cdn.cheeko.ai/skills/abc123/images/page2.jpg"}
  ]
}

Firmware download and play flow:

card_content received
    │
    ▼
Background download task:
    1. Create dir: /sdcard/cheeko/skills/<skill_id>/
    2. Download each audio URL → /sdcard/cheeko/skills/<skill_id>/audio/track<n>.mp3
    3. Download each image URL → /sdcard/cheeko/skills/<skill_id>/images/page<n>.jpg
    4. Write manifest.jsn LAST (marks download complete)
    5. Update cardmap.jsn: UID → skill_id
    │
    ▼
Play content from SD

Important firmware rules:

Write manifest.jsn last — it is the completion marker. If firmware crashes mid-download, the next boot will retry the download (manifest absent = incomplete).
If card is removed during download → abort download, do NOT auto-play when download finishes.
Download must run in a background task — main event loop must stay responsive.

11.6 Card Types from Manager API

The Manager API card/lookup response contentType field determines gateway routing:

`contentType`	Gateway behavior
`story_pack` / `rhyme_pack` / `habit_pack`	Send `card_content` to firmware
`prompt`	Route `promptText` to LiveKit agent as `user_text` (no SD download)
`prompt_pack`	Route prompt to LiveKit as `user_text`
`read_only`	Send `contentText` directly as TTS without LLM (via `user_text` with read_only flag)

For prompt and read_only cards, firmware may receive a tts start and audio response without having sent a listen start — this is the gateway routing a scripted response.

11.7 Legacy Download Response (Backward Compatibility)

Gateway also handles older download_response format for legacy firmware:

{"type":"download_response","status":"not_found","rfid_uid":"04A1B2C3D4"}
{"type":"download_response","status":"up_to_date","rfid_uid":"04A1B2C3D4","pack_code":"fox_story","version":"2"}
{"type":"download_response","status":"download_required","rfid_uid":"04A1B2C3D4","pack_code":"fox_story","files":{...}}
{"type":"download_response","status":"error","rfid_uid":"04A1B2C3D4","message":"Server error"}

New firmware should use card_content / card_ai / card_unknown instead.

12. Device State Machine

12.1 State List

State	Description
`starting`	Boot, hardware init
`wifi_configuring`	Wi-Fi provisioning
`activating`	OTA check + activation loop
`idle`	Fully connected, waiting for user action
`connecting`	Opening MQTT hello + UDP channel
`listening`	Mic active, streaming audio uplink
`speaking`	Playing TTS downlink audio
`upgrading`	Downloading and flashing OTA firmware
`audio_testing`	Audio hardware test mode
`fatal_error`	Unrecoverable error

12.2 State Transitions

starting
  └─ Wi-Fi connected → wifi_configuring (if no creds) | activating (if creds stored)

activating
  └─ OTA check done, firmware update needed → upgrading
  └─ Need activation → loop /ota/activate until 200
  └─ Activated → idle

idle
  └─ User presses button / wake word → connecting
  └─ AI card tapped (prewarm) → connecting (background, silent)
  └─ Content card known on SD → play from SD (stays idle after playback)

connecting
  └─ hello sent, server hello received, UDP open → listening
  └─ User cancels (button in connecting state) → idle
  └─ Timeout (no server hello in 10s) → idle

listening
  ├─ Sending: listen(state=start), UDP audio uplink
  ├─ Button/PTT release → send speech_end → stays in listening until tts start
  ├─ listen(state=stop) sent → idle (manual stop)
  ├─ 30s silence timeout → idle (close session)
  └─ Receive tts(state=start) → speaking

speaking
  ├─ Receiving: UDP audio downlink, tts/stt/llm MQTT messages
  ├─ Wake word detected → send abort → send listen(start) → listening
  ├─ Button press → send abort → send listen(start) → listening
  └─ Receive tts(state=stop):
        manual mode → idle
        auto/realtime → listening

upgrading
  └─ Flash complete → reboot → starting

fatal_error
  └─ Manual reset only

12.3 Encoder Button Behavior (jiuchuan board)

Current State	Button Action	Firmware Behavior
`listening`	Press	Send `speech_end` (end user turn)
`speaking`	Press	Send `abort` (interrupt assistant)
`connecting`	Press	Cancel connection attempt → `idle`
`idle` + prewarmed	Press	Send `listen start` (instant conversation)
`idle` + content card	Press	Play/pause/next track on SD
`idle`	Press	Start connecting → `connecting`

13. MQTT Message Reference

13.1 Firmware → Gateway (Uplink)

`hello`

{
  "type": "hello",
  "version": 3,
  "transport": "udp",
  "features": { "mcp": true },
  "audio_params": {
    "format": "opus",
    "sample_rate": 16000,
    "channels": 1,
    "frame_duration": 60
  }
}

`listen` — start

{
  "session_id": "abc123_AABBCCDDEEFF_conversation",
  "type": "listen",
  "state": "start",
  "mode": "manual"
}

mode values: manual | auto | realtime

`listen` — stop

{
  "session_id": "...",
  "type": "listen",
  "state": "stop"
}

`listen` — detect (wake word)

{
  "session_id": "...",
  "type": "listen",
  "state": "detect",
  "text": "hey cheeko"
}

`speech_end`

{
  "session_id": "...",
  "type": "speech_end"
}

`abort`

{
  "session_id": "...",
  "type": "abort",
  "reason": "wake_word_detected"
}

reason values: wake_word_detected | button_pressed | user_interrupt

`goodbye`

{
  "session_id": "...",
  "type": "goodbye"
}

`mcp` (tool call from device to agent)

{
  "session_id": "...",
  "type": "mcp",
  "payload": {
    "id": "call_001",
    "function": "self.audio_speaker.set_volume",
    "params": { "volume": 80 }
  }
}

`card_lookup`

{
  "session_id": "...",
  "type": "card_lookup",
  "rfid_uid": "04A1B2C3D4"
}

13.2 Gateway → Firmware (Downlink)

`hello` (server hello)

{
  "type": "hello",
  "version": 3,
  "mode": "conversation",
  "session_id": "abc123_AABBCCDDEEFF_conversation",
  "transport": "udp",
  "udp": {
    "server": "192.168.1.100",
    "port": 1883,
    "encryption": "aes-128-ctr",
    "key": "0102030405060708090a0b0c0d0e0f10",
    "nonce": "101112131415161718191a1b1c1d1e1f",
    "connection_id": 987654321,
    "cookie": 987654321
  },
  "audio_params": {
    "sample_rate": 24000,
    "channels": 1,
    "frame_duration": 60,
    "format": "opus"
  }
}

`mode_update`

{
  "type": "mode_update",
  "mode": "conversation",
  "listening_mode": "auto",
  "character": "Cheeko",
  "session_id": "...",
  "timestamp": 1710000000000
}

`tts` — start

{
  "type": "tts",
  "state": "start",
  "session_id": "...",
  "text": "Hello! I'm Cheeko."
}

text is optional and may be absent.

`tts` — sentence_start

{
  "type": "tts",
  "state": "sentence_start",
  "session_id": "...",
  "text": "Once upon a time..."
}

`tts` — stop

{
  "type": "tts",
  "state": "stop",
  "session_id": "..."
}

`stt` (user transcript)

{
  "type": "stt",
  "text": "Tell me a story about a fox",
  "session_id": "..."
}

`llm` — thinking indicator

{
  "type": "llm",
  "state": "think",
  "session_id": "..."
}

`llm` — text response

{
  "type": "llm",
  "text": "Once upon a time, there was a clever fox...",
  "session_id": "..."
}

`llm` — text with emotion

{
  "type": "llm",
  "text": "I'm so happy you asked!",
  "emotion": "happy",
  "session_id": "..."
}

emotion values: happy | sad | thinking | excited | circle_xmark

`alert`

{
  "type": "alert",
  "status": "error",
  "message": "Connection to AI service failed",
  "emotion": "circle_xmark",
  "session_id": "..."
}

`agent_ready`

{
  "type": "agent_ready"
}

`goodbye` (server-initiated)

{
  "type": "goodbye",
  "session_id": "...",
  "reason": "inactivity_timeout"
}

reason values: inactivity_timeout | error | disconnect | mode_change

`card_unknown`

{
  "type": "card_unknown",
  "rfid_uid": "04A1B2C3D4"
}

`card_ai`

{
  "type": "card_ai",
  "rfid_uid": "04A1B2C3D4"
}

`card_content`

{
  "type": "card_content",
  "rfid_uid": "04A1B2C3D4",
  "skill_id": "skill_abc123",
  "skill_name": "The Hungry Fox Story",
  "version": 1,
  "audio": [
    {"index": 1, "url": "https://cdn.cheeko.ai/skills/abc123/audio/track1.mp3"},
    {"index": 2, "url": "https://cdn.cheeko.ai/skills/abc123/audio/track2.mp3"}
  ],
  "images": [
    {"index": 1, "url": "https://cdn.cheeko.ai/skills/abc123/images/page1.jpg"},
    {"index": 2, "url": "https://cdn.cheeko.ai/skills/abc123/images/page2.jpg"}
  ]
}

13.3 Message Semantics — Required Firmware Behavior

Incoming Message	Required Firmware Action
`listen state=start`	Enter listening behavior; start mic capture and UDP uplink
`listen state=stop`	Stop mic capture; return to idle
`speech_end`	Stop mic capture immediately; show thinking UI; wait for `tts start`
`tts state=start`	Enter speaking behavior; start playing UDP downlink audio
`tts state=sentence_start`	Optional: update on-screen transcript
`tts state=stop`	End speaking; transition by mode: manual→idle, auto/realtime→listening
`stt`	Update user transcript text on display/log; no state transition
`llm state=think`	Show thinking indicator (before TTS starts)
`llm text/emotion`	Update assistant text/emotion UI; no transport change
`abort` (sent by firmware)	Use for interrupting speaking or playback; send immediately on wake-word interruption during speaking
`goodbye`	Close current session; reset local session variables
`card_content`	Download audio/images to SD; write manifest last; update card map
`card_ai`	Mark UID as AI card; trigger/prewarm conversation behavior
`card_unknown`	Show card-not-recognized UX and stop waiting

14. UDP Packet Format

14.1 Header (16 bytes, big-endian)

Offset  Size  Type      Field           Notes
------  ----  --------  --------------- -----------------------------------------
0       1     uint8     packet_type     1 = audio packet
1       1     uint8     flags           reserved, currently 0
2-3     2     uint16be  payload_length  length of encrypted payload in bytes
4-7     4     uint32be  connection_id   from server hello udp.connection_id
8-11    4     uint32be  timestamp       milliseconds (local clock, for jitter calc)
12-15   4     uint32be  sequence        monotonically increasing per sender

14.2 Payload (bytes 16 onward)

Encrypted Opus audio using AES-128-CTR.

Key: udp.key from server hello (hex string, hex-decode to 16 bytes)
Nonce/IV: udp.nonce from server hello (hex string, hex-decode to 16 bytes)
Each packet uses the nonce, modified by sequence number for counter mode

14.3 Uplink (Firmware → Gateway)

Parameter	Value
Sample rate	16000 Hz
Channels	1 (mono)
Codec	Opus
Frame duration	60ms
Frame size	16000 × 0.060 = 960 samples per frame

14.4 Downlink (Gateway → Firmware)

Parameter	Value
Sample rate	24000 Hz
Channels	1 (mono)
Codec	Opus
Frame duration	60ms

Note: Firmware records at 16kHz; gateway resamples uplink from 16kHz to 24kHz before sending to LiveKit. Assistant audio comes back at 24kHz and is sent as-is to firmware. Firmware DAC must support 24kHz playback.

14.5 Validation Rules

Ignore packets where packet_type != 1.
Ignore packets where total length < 16 (malformed header).
Track remote sequence number; reject stale out-of-order packets.
Keep local sequence counter for uplink; increment per packet sent.

15. Manager API Endpoints

Base path: /toy (all endpoints below are relative to it).

15.1 Firmware Uses Directly

Method	Endpoint	Auth	Purpose
`POST`	`/ota/`	None (public)	Boot OTA check, get MQTT credentials
`POST`	`/ota/activate`	None (public)	Activation polling loop
`GET`	`/otaMag/download/<id>`	None	Firmware binary download

15.2 Gateway Uses (on behalf of device)

Method	Endpoint	Purpose
`GET`	`/device/:mac/mode`	Get device mode (`conversation`/`music`/`story`)
`GET`	`/device/:mac/device-mode`	Get listening mode (`auto`/`manual`)
`POST`	`/device/:mac/cycle-mode`	Cycle to next mode
`GET`	`/agent/device/:mac/current-character`	Get current character name
`POST`	`/agent/device/:mac/set-character`	Set specific character
`POST`	`/agent/device/:mac/cycle-character`	Cycle to next character
`POST`	`/config/child-profile-by-mac`	Get child profile (age, name, preferences)
`GET`	`/device/:mac/playlist/music`	Get music playlist
`GET`	`/device/:mac/playlist/story`	Get story playlist
`GET`	`/admin/rfid/card/lookup/:rfidUid`	RFID card lookup
`GET`	`/admin/rfid/card/content/download/:rfidUid`	Content pack download manifest

15.3 Standard Response Format

Most Manager API endpoints return:

{
  "code": 0,
  "msg": "success",
  "data": { ... }
}

Exceptions:

/toy/ota/ returns raw JSON (no wrapper).
/toy/ota/activate returns plain text success or empty body.

16. Gateway Internal API Calls

This section describes what the gateway does internally after receiving device messages — firmware does not call these directly, but understanding them explains timing and behavior.

16.1 On Device Hello

Gateway receives hello from device
    │
    ├─ GET /toy/device/:mac/mode
    │   Response: {code:0, data:"conversation"}
    │
    ├─ GET /toy/device/:mac/device-mode
    │   Response: {code:0, data:"auto"}
    │
    ├─ GET /toy/agent/device/:mac/current-character
    │   Response: {code:0, data:{characterName:"Cheeko"}}
    │
    └─ POST /toy/config/child-profile-by-mac
        Body: {"macAddress":"AA:BB:CC:DD:EE:FF"}
        Response: {code:0, data:{name:"Aria", age:6, language:"en"}}

After all four complete, gateway:

Sends mode_update to device.
Dispatches appropriate LiveKit agent worker.

16.2 On RFID Card Lookup

Gateway receives card_lookup from device
    │
    └─ GET /toy/admin/rfid/card/lookup/:rfidUid
        Response:
        {
          "code": 0,
          "data": {
            "contentType": "story_pack|rhyme_pack|habit_pack|prompt|prompt_pack|read_only",
            "title": "The Hungry Fox",
            "packName": "Fox Adventures Vol 1",
            "packCode": "fox_vol1",
            "contentText": "Once upon a time...",   ← for read_only
            "promptText": "Tell me about a fox",    ← for prompt
            "language": "en",
            "items": [
              {
                "index": 1,
                "audioUrl": "https://...",
                "imageUrl": "https://..."
              }
            ]
          }
        }

Gateway then decides:

story_pack / rhyme_pack / habit_pack → also calls GET /toy/admin/rfid/card/content/download/:rfidUid → sends card_content to firmware
prompt / prompt_pack → sends promptText as user_text to LiveKit agent data channel
read_only → sends contentText as user_text with read_only flag to agent

17. LiveKit Data Channel Messages

These are internal messages between the MQTT Gateway and the LiveKit Python agent workers. Firmware does not see these directly — they drive the AI behavior. Included here for completeness.

17.1 Gateway → Agent

Message	Trigger	Purpose
`ptt_event`	Device sends `listen start`	Start recording user audio in agent
`speech_end`	Device sends `speech_end`	End user turn, trigger AI response
`abort`	Device sends `abort`	Stop current AI generation
`disconnect_agent`	Device sends `goodbye`	Clean up agent session
`ready_for_greeting`	Agent joins room	Trigger initial greeting
`end_prompt`	Session ending	Tell agent to wrap up
`user_text`	RFID prompt/read_only card	Inject text as if user said it
`mcp`	Device sends `mcp`	Forward tool call to agent

17.2 Agent → Gateway

Event	Meaning	Gateway Action
`agent_state_changed`	speaking/listening state change	Send `tts start/stop` to device
`speech_created`	Agent audio ready	Stream audio to device via UDP
`lk.transcription`	User/agent transcription stream	Send `stt`/`llm text` to device
`lk.agent.events`	Agent lifecycle events	Track agent join/leave

17.3 `cheeko_worker.py` Handled Message Types

The Python agent worker explicitly handles:

ready_for_greeting → sends greeting to child
end_prompt → graceful session end
shutdown_request → hard shutdown
user_text → inject as user message (for RFID prompt routing)

Known gap: ptt_event, speech_end, and abort are sent by the gateway to the agent but the worker does not have explicit handlers for these — they are handled by the LiveKit SDK's built-in agent session flow.

18. Timeouts and Retries

Use these values for compatibility with current backend behavior:

Timeout	Duration	Action
Server hello wait	10s	Retry or fall back
Listening inactivity	30s	Send goodbye, go idle
Thinking (after speech_end)	20s	Close session, go idle
Unknown RFID response	10s	Show "not recognized"
Activation retry interval	~3s	Retry `/ota/activate`
OTA check retry	10s (exponential)	Retry `/ota/` up to 10 times
RFID API call (gateway)	5s	Gateway timeout on Manager API call

19. Persistence Keys

Persist these settings so firmware can reconnect after reboot without re-running OTA check:

MQTT (store to NVS):

endpoint
client_id
username
password
publish_topic
subscribe_topic

WebSocket fallback:

websocket.url

RFID local metadata (store to SD card):

UID -> skill_id map (cardmap.jsn)
Per-skill manifest marker (skills/<skill_id>/manifest.jsn)

20. Minimal Conformance Checklist

A firmware build is integration-ready when all checks pass:

#	Check
1	Can complete OTA check and parse `activation`/`mqtt`/`firmware`/`server_time`
2	Can activate with `/ota/activate` retry behavior
3	Can MQTT connect with OTA credentials
4	Can perform `hello` handshake and open UDP channel
5	Can send uplink audio and play downlink audio via UDP
6	Can process `tts start/stop` and maintain speaking/listening transitions
7	Can send `speech_end` and receive response turn correctly
8	Can send `abort` during speaking and recover to listening
9	RFID local cache path works fully offline
10	RFID unknown path works via `card_lookup` → `card_content`/`card_ai`/`card_unknown`
11	Card removal properly stops playback/session
12	Handles `goodbye` cleanly and can start a new session

Appendix A: MQTT Topic Summary

Direction	Topic	Notes
Device → Gateway	`device-server`	From OTA `publish_topic`; all device messages go here
Gateway → Device	`devices/p2p/<client_id>`	Derived from OTA `client_id`
EMQX → Gateway	`internal/server-ingest`	Internal EMQX republish; envelope has `sender_client_id` + `orginal_payload` (typo intentional in field name)

Appendix B: Session ID Format

<uuid>_<mac_without_colons>_<mode>

Examples:
  abc123def456_AABBCCDDEEFF_conversation
  abc123def456_AABBCCDDEEFF_music

Appendix C: Source Code Anchors

Firmware side:

File	Contents
`main/ota.cc`	OTA check and activation loop
`main/application.cc`	Top-level application state machine
`main/protocols/protocol.cc`	Base protocol interface
`main/protocols/mqtt_protocol.cc`	MQTT protocol implementation
`main/device_state_machine.cc`	Device state machine
`main/boards/common/content_manager.cc`	RFID and content management
`main/boards/jiuchuan-s3/jiuchuan_dev_board.cc`	Board-specific I/O (button, encoder)

Gateway and API side (interfaces consumed by firmware):

File	Contents
`main/manager-api-node/src/routes/ota.routes.js`	OTA endpoint handlers
`main/manager-api-node/src/services/device.service.js`	Device config service
`main/mqtt-gateway/mqtt/virtual-connection.js`	Per-device virtual connection
`main/mqtt-gateway/gateway/mqtt-gateway.js`	MQTT message routing
`main/mqtt-gateway/livekit/livekit-bridge.js`	LiveKit audio and data bridge

Table of Contents​

1. System Overview​

What the Firmware Must Implement​

External Interfaces Firmware Uses​

2. Full Boot-to-Conversation Flow​

3. Phase 1 — OTA Check​

Request​

Response​

Response Field Reference​

Firmware Rules​

4. Phase 2 — Activation Loop​

Responses​

Firmware Rules​

5. Phase 3 — MQTT Connect and Hello Handshake​

5.1 MQTT Connection Parameters​

5.2 Device Hello Message​

5.3 Gateway Processing on Hello​

5.4 Gateway Server Hello (Response)​

6. Phase 4 — UDP Channel Setup​

7. Phase 5 — Mode Update (Deferred)​

Gateway API Calls on Hello​

mode_update Message​

8. Phase 6 — Conversation Loop​

8.1 User Starts Speaking (PTT or Wake Word)​

8.2 Wake Word Detection Event​

8.3 User Stops Speaking (PTT Release)​

8.4 Gateway Thinking Indicator​

8.5 Gateway Starts Speaking​

8.6 Gateway Sentence Start (Text Update)​

8.7 User Transcript from STT​

8.8 LLM Text and Emotion​

8.9 Gateway Stops Speaking​

8.10 Alert Message​

8.11 Agent Ready Signal​

8.12 Conversation Timing Diagram​

9. Phase 7 — Abort / Interrupt​

9.1 Firmware Interrupts During Speaking​

9.2 Firmware Behavior on Sending Abort​

9.3 Gateway Behavior on Receiving Abort​

10. Phase 8 — Session End​

10.1 Device Initiates Goodbye​

10.2 Gateway Initiates Goodbye (Inactivity Timeout)​

10.3 Firmware Behavior on Receiving Goodbye​

11. RFID Card Flow​

11.1 Card Tapped — Local SD Cache Check​

11.2 Card Lookup Request (Unknown Card)​

11.3 Response A — Unknown Card​

11.4 Response B — AI Card​

11.5 Response C — Content Card (Story/Song/Habit/Rhyme Pack)​

11.6 Card Types from Manager API​

11.7 Legacy Download Response (Backward Compatibility)​

12. Device State Machine​

12.1 State List​

12.2 State Transitions​

12.3 Encoder Button Behavior (jiuchuan board)​

13. MQTT Message Reference​

13.1 Firmware → Gateway (Uplink)​

hello​

listen — start​

listen — stop​

listen — detect (wake word)​

speech_end​

abort​

goodbye​

mcp (tool call from device to agent)​

card_lookup​

13.2 Gateway → Firmware (Downlink)​

hello (server hello)​

mode_update​

tts — start​

tts — sentence_start​

tts — stop​

stt (user transcript)​

llm — thinking indicator​

llm — text response​

llm — text with emotion​

alert​

agent_ready​

goodbye (server-initiated)​

card_unknown​

Table of Contents

1. System Overview

What the Firmware Must Implement

External Interfaces Firmware Uses

2. Full Boot-to-Conversation Flow

3. Phase 1 — OTA Check

Request

Response

Response Field Reference

Firmware Rules

4. Phase 2 — Activation Loop

Responses

Firmware Rules

5. Phase 3 — MQTT Connect and Hello Handshake

5.1 MQTT Connection Parameters

5.2 Device Hello Message

5.3 Gateway Processing on Hello

5.4 Gateway Server Hello (Response)

6. Phase 4 — UDP Channel Setup

7. Phase 5 — Mode Update (Deferred)

Gateway API Calls on Hello

mode_update Message

8. Phase 6 — Conversation Loop

8.1 User Starts Speaking (PTT or Wake Word)

8.2 Wake Word Detection Event

8.3 User Stops Speaking (PTT Release)

8.4 Gateway Thinking Indicator

8.5 Gateway Starts Speaking

8.6 Gateway Sentence Start (Text Update)

8.7 User Transcript from STT

8.8 LLM Text and Emotion

8.9 Gateway Stops Speaking

8.10 Alert Message

8.11 Agent Ready Signal

8.12 Conversation Timing Diagram

9. Phase 7 — Abort / Interrupt

9.1 Firmware Interrupts During Speaking

9.2 Firmware Behavior on Sending Abort

9.3 Gateway Behavior on Receiving Abort

10. Phase 8 — Session End

10.1 Device Initiates Goodbye

10.2 Gateway Initiates Goodbye (Inactivity Timeout)

10.3 Firmware Behavior on Receiving Goodbye

11. RFID Card Flow

11.1 Card Tapped — Local SD Cache Check

11.2 Card Lookup Request (Unknown Card)

11.3 Response A — Unknown Card

11.4 Response B — AI Card

11.5 Response C — Content Card (Story/Song/Habit/Rhyme Pack)

11.6 Card Types from Manager API

11.7 Legacy Download Response (Backward Compatibility)

12. Device State Machine

12.1 State List

12.2 State Transitions

12.3 Encoder Button Behavior (jiuchuan board)

13. MQTT Message Reference

13.1 Firmware → Gateway (Uplink)

`hello`

`listen` — start

`listen` — stop

`listen` — detect (wake word)

`speech_end`

`abort`

`goodbye`

`mcp` (tool call from device to agent)

`card_lookup`

13.2 Gateway → Firmware (Downlink)

`hello` (server hello)

`mode_update`

`tts` — start

`tts` — sentence_start

`tts` — stop

`stt` (user transcript)

`llm` — thinking indicator

`llm` — text response

`llm` — text with emotion

`alert`

`agent_ready`

`goodbye` (server-initiated)

`card_unknown`
